Karakteristikler
| LOA - 10.15m (33'4") | LWL 8.00m 26'3") | Beam 3.30m (10'10") | Draft 1.70m (5''7") |
| Displacement 4475kg (9863lb) | Ballast 1742kg (2840lb) | Area Waterplane 15.63sq.m (168sq.ft) | Immersion Rate 160kg/cm (882 lb/in) |
| Wetted Surface 23.39sq.m (252sq.ft) | Fineness Coef 0.68 | Block Coef 0.40 | Prismatic Coef 0.57 |
| Displacement/Length 244 | Sail Area (Main + Fore-triangle) 47.32sq.m (509sq.ft) | Sail Area/Wetted Surface 2.02 | Sail Area/Displ 17.6 |
| Righting Moment @ 30 deg 2926 kgm (1966ft.lb) | Righting Moment @ 60 deg 4043 kgm (2717ft.lb) | Righting Moment @ 90 deg 2768 kgm (1860ft.lb) | Powering 10-20hp inboard diesel |
