Didi 34

Didi 34 radius chine plywood boat



Didi 34 radius chine plywood boat



Didi 34 radius chine plywood boat



Didi 34 radius chine plywood boat



Didi 34 radius chine plywood boat



Karakteristikler

LOA 10,50m (34'5")

LWL 9,60m (31'6")

Beam 3,40m (11'2")

Draft 1.5m (4' 11") or
1,90m (6' 3")

Displ to DWL 4300kg (9477lb)

Displ IMS trim
3600kg (7935lb) deep keel
3830kg (8442lb) shallow keel

Ballast
1730kg (3813lb) deep keel
1960kg (4320lb) shallow keel

Waterplane area 17.07sq.m (184sq.ft)

Immersion rate 175kg/cm (980lb/inch)

Wetted surface 24.4sq.m (263sq.ft)

Sail area (main + 100% fore triangle) 49.8sq.m (536sq.ft)

Sail Area/Wetted Surface 2.04

Sail Area/Displ 18.7

Displ/length 135

Prismatic coef .56

Block coef .43

Fineness coef .66

Righting Moment @ 30 deg 2908kgm (21034ft.lb)

Righting Moment @ 60 deg 3912kgm (28296ft.lb)

Righting Moment @ 90 deg 2952kgm (21352ft.lb)

I 12,24m (40'2")

J 3,62m (11'10")

P 12,50m (35'11")

E 4,5m (14'9")

Mainsail (excl roach) 28,13sq.m (303sq.ft)

Foretriangle 21,70sq.m (234sq.ft)

150% Genoa 38,28sq.m (412sq.ft)

Powering 15-25hp diesel

Headroom aft 1.87m (6'2")

Headroom at mast 1.76m (5'9")

Fuel 150 litres (41 US gals)

Water 600 litres (165 US gals)
