LOA 6.50m (21'4")

LWL 6.45m (21'2")

Beam 3.00m (9'10")

Draft
0.8m/1.6m (2' 8"/5' 3")lifting
2.00m (6' 7") fixed

Displ light
1000kg (2204lb) lifting
850kg (1873lb) fixed

Displ half load
1300kg (2865lb) lifting
1150kg (2535lb) fixed

Ballast 435kg (960lb) lifting
320kg (705lb) fixed

Waterplane area 8.75sq.m (94sq.ft)

Immersion rate 90kg/cm (504lb/inch)

Wetted surface 12sq.m (129sq.ft)

Sail area (main + jib) 29.35sq.m (316sq.ft)

Sail Area/Wetted Surface 2.45

Sail Area/Displ 24.9

Displ/length 135

Prismatic coef .54

Block coef .44

Fineness coef .67

Righting Moment @ 30 deg 835kgm (6040ft.lb)

Righting Moment @ 60 deg 1060kgm (7667ft.lb)

Righting Moment @ 90 deg 540kgm (3905ft.lb)

IG 8.62m (28'4")

ISP 8.97mm (29'5")

J 2.585m (8'6")

P 9.20m (30'2")

E 3.25m (10'8")

Mainsail 19.02sq.m (205sq.ft)

Solent Jib 10.33sq.m (111sq.ft)

150% Genoa 16.67sq.m (179sq.ft)
