Karakteristikler
| LOA - 11.70m (38' 5") | LWL 10.25m (33' 7") | Beam 3.80m (12' 6") | Draft 1.5 & 1.75m (4' 11" & 5' 9") |
| Displacement 10000kg (22040lb) | Ballast 2800kg (6171lb) | Area Waterplane 22.66sq.m (244sq.ft) | Immersion Rate 231kg/cm (1293lb/inch) |
| Wetted Surface 36.3sq.m (390.6sq.ft) | Fineness Coef 0.67 | Block Coef 0.40 | Prismatic Coef 0.55 |
| Displacement/Length 259 | Sail Area (Main + Fore-triangle) 67.0sq.m (720.9sq.ft) | Sail Area/Wetted Surface 1.85 | Sail Area/Displ 14.9 |
| Righting Moment @ 30 deg 5399 kgm (39051ftlb) | Righting Moment @ 60 deg 7497 kgm (54226ftlb) | Righting Moment @ 90 deg 5419 kgm (39195ftlb) | Powering30-40hp inboard diesel |
