Hout Bay 33

Hout Bay 33 radius chine steel cruiser boat plans



Hout Bay 33 radius chine steel cruiser boat plans



Hout Bay 33 radius chine steel cruiser boat plans



Hout Bay 33 radius chine steel cruiser boat plans



Hout Bay 33 radius chine steel boat plans



Karakteristikler

LOA 10.25m (33'7") LWL 8.50m (27'10") Beam 3,30m (10'10") Draft 1,50m (4'11")
Displacement 8000kg (17632lb) Ballast [all lead] 2500kg (5510lb) Area Waterplane 17.9sq.m (193sq.ft) Immersion Rate 183kg/cm (1024lb/inch)
Wetted Surface 29.4sq.m (316sq.ft) Fineness Coef 0,69 Block Coef 0,38 Prismatic Coef 0,55
Displacement/Length 363 Sail Area [Main + Fore-triangle] 58.3sq.m (628sq.ft) Sail area/displ 14.73 Powering 20hp inboard diesel
Righting Moment @ 30 deg 3433kgm (24830ft.lb) Righting Moment @ 60 deg 5979kgm (43245ft.lb) Righting Moment @ 90 deg 5473kgm (39585ft.lb) Headroom 1.86m (6' 1")
