Characteristics
| LOA 14.4m (47'3") | LWL 12.5m (41'0") | Beam 4.30m (14'1") | Displacement 14900kg (32840lb) |
| Ballast 4200kg (9257lb) | Area Waterplane 30.8sq.m (332sq.ft) | Immersion Rate 315kg/cm (1763lb/inch) | Fineness Coef 0.69 |
| Block Coef 0.46 | Prismatic Coef 0.57 | Displ/Length 213 | Powering 75hp diesel |
| Schooner/Swing keel | Cutter/Fin keel | |
| Draft | 1.05/2.55m (3'5"/8'4") | 1.80m (5'11") |
| Wetted Surface | 48.7sq.m (524sq.ft) | 48.1sq.m (518sq.ft) |
| Sail Area (with 100% fore-triangle) | 99.3sq.m (1069sq.ft) | 93.3sq.m (1004sq.ft) |
| Ditto (Total light weather) | 109.7sq.m (1181sq.ft) | 109.3sq.m (1176sq.ft) |
| Sail Area/Displacement (working) | 16.6 | 15.6 |
| Sail Area/Wetted Surface (working) | 2.04 | 1.94 |
| Ditto (light weather) | 2.25 | 2.27 |
| Righting Moment 30degrees | 9250kgm (66905ft.lb) | 9503kgm (68735ft.lb) |
| Ditto 60degrees | 12868kgm (93074ft.lb) | 13645kgm (98694ft.lb) |
| Ditto 90degrees | 9640kgm (69726ft.lb) | 10577kgm (76504ft.lb |
