Windy 900

Cape Henry 21 plywood trailer sailer



Cape Henry 21 plywood trailer sailer





Cape Henry 21 plywood trailer sailer



Cape Henry 21 plywood trailer sailer



Cape Henry 21 plywood trailer sailer



Cape Henry 21 plywood trailer sailer



Karakteristikler

LOA 8.90m (29'2")

LWL 8.35m (27'5")

Beam 3.12m (10'3")

Draft 1.70m (5'7")

Displ 3000kg (6612lb)

Ballast 950kg (2094lb)

Area Waterplane 12.91sq.m (139sq.ft)

Immersion Rate 132kg/cm (739lb/in)

Fineness Coef 0.67

Block Coef 0.39

Prismatic Coef 0.57

Wetted Surface 18.9sq.m (203sq.ft)

Sail Area short rig
(Main + Fore-triangle) 31.2sq.m (336sq.ft)

Sail Area tall rig
(Main + Fore-triangle)
35.6sq.m (383sq.ft)

Sail Area/Wetted Surface
1.65 (short rig)
1.88 (tall rig)

Displ/Length 144

Sail Area/Displ
15.2 (short rig)
17.3 (tall rig)

Righting Moment @ 30 deg 1701kgm (12303ft.lb)

Righting Moment @ 60 deg 2404kgm (17388ft.lb)

Righting Moment @ 90 deg 1481kgm (10712ft.lb)

Headroom aft - 1.94m (6'4")

Headroom at mast - 1.8m (5'11")
